EcoFlow Extra Battery Compatibility Matrix

Extra battery compatibility is a complex topic despite the fact that many extra batteries and solar generators share the same XT-150 connector. For the most part, extra batteries only work with their main unit:

• RIVER Pro Extra Battery to RIVER Pro solar generator
• WAVE Add-on Battery to WAVE air conditioner
• WAVE 2 Add-on Battery to WAVE heat pump
• DELTA Pro Extra Battery to DELTA Pro solar generator
• Power Kits Batteries to Power Kits Hub

When the DELTA 2 and the DELTA 2 Max were released, EcoFlow did something interesting with the extra battery situation, allowing some mixing and matching of extra batteries and solar generators. The DELTA Pro 3 can use both the DELTA Pro extra battery and the DELTA Pro 3 extra battery, though in practice mixing two different battery sizes causes sequential draining and filling of the different battery types. With the introduction of the DELTA 3 and DELTA 3 Plus, EcoFlow also added the ability to add the mighty DELTA Pro 3 Extra Battery for a whopping total 5 kilowatt hours of capacity with the solar generator and extra battery.

RIVER Series

	Acronym	RP EB	R3+ EB300	R3+ EB600
Connector		Dsub 7w2	TBD	TBD0
RIVER Pro	RP	thumb_up	thumb_down	thumb_down
RIVER 2	R2	thumb_down	thumb_down	thumb_down
RIVER 2 Max	R2M	thumb_down	thumb_down	thumb_down
RIVER 2 Pro	R2P	thumb_down	thumb_down	thumb_down
RIVER 3 New	R3	thumb_down	thumb_down	thumb_down
RIVER 3 Plus New	R3+	thumb_down	thumb_up1	thumb_up2

¹ RIVER 3 Max = RIVER 3 Plus + EB 300
² RIVER 3 Max Plus = RIVER 3 Plus + EB 600

DELTA Series

	Acronym	D2 EB	D3 EB New	DM EB	D2M EB	DP EB	DP3 EB New	PK 2kwh	PK 5kwh	W1 EB	W2 EB	BLADE EB	800w Alternator Charger
Connector		XT-150	XT-150	XT-150	XT-150	4+8	4+8	4+8	4+8	XT-150	XT-150	XT-150	XT-150
Chemistry		LFP	LFP	NMC	LFP	LFP	LFP	LFP	NMC	NMC	LFP	-
DELTA Mini		thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down
DELTA (1000)		thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down
DELTA (1300)		thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down
DELTA Max (1600)	DM	thumb_down	thumb_down	thumb_up	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	question_mark	thumb_down	thumb_up
DELTA Max (2000)	DM	thumb_down	thumb_down	thumb_up	thumb_up	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	question_mark	thumb_down	thumb_up
DELTA 2	D2	thumb_up	thumb_up	thumb_up	thumb_up	thumb_up1 4	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up	thumb_up	thumb_up
DELTA 3/3 Plus New	D3/D3+	thumb_up	thumb_up	thumb_down	thumb_up	thumb_up1 4	thumb_up	thumb_down	thumb_down	thumb_down	thumb_up	thumb_down	thumb_up
DELTA 2 Max	D2M	thumb_down	thumb_down	thumb_up	thumb_up	thumb_up1 4	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up	thumb_down	thumb_up
DELTA Pro	DP	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up1 2	thumb_down	thumb_up1
DELTA Pro 3 New	DP3	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up	thumb_up	thumb_down	thumb_down	thumb_down	question_mark	thumb_down	thumb_up1
Power Kits	PK	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up	thumb_up	thumb_down	thumb_down	thumb_down	thumb_down
Power Kits 5kVA New		thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up	thumb_up	thumb_down	thumb_down	thumb_down	thumb_down
Power Kits PowerDock New		thumb_up	thumb_up	thumb_down	thumb_up	thumb_up	thumb_up	thumb_up	thumb_up	thumb_down	thumb_down	thumb_down	thumb_down
WAVE	W1	thumb_up	thumb_up	thumb_up	thumb_up	thumb_up1	question_mark	question_mark	question_mark	thumb_up	thumb_down	thumb_down	thumb_down
WAVE 2	W2	thumb_up	thumb_up	thumb_up	thumb_up	thumb_up1	question_mark	question_mark	question_mark	thumb_down	thumb_up	thumb_down	thumb_down3
BLADE		thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_down	thumb_up	thumb_down
Smart Generator	SG	thumb_up	thumb_up	thumb_up	thumb_up	thumb_up1	question_mark	question_mark	question_mark	thumb_down	question_mark	thumb_down	-
800w Alternator Charger	800wAC	thumb_up	thumb_up	thumb_up	thumb_up	thumb_up1	question_mark	question_mark	question_mark	thumb_down	thumb_up3	thumb_down	-

1. Requires an XT-150 to 4+8 adapter (a.k.a EcoFlow DELTA Pro to Smart Generator Adapter)
2. Disables AC output while WAVE 2 battery is plugged in
3. Can charge the WAVE 2 battery but cannot power the WAVE 2
4. Main unit discharges first and charges last. Not supported by EF but seems to work. Use at your own risk

DPU - DELTA Pro Ultra

The DELTA Pro Ultra is a completely new design which comes with a 5+8 battery connector which is incompatible with any of the DELTA extra batteries in the table above. These work at a completely different voltage from the rest of the DELTA series so you cannot plug any of the other DELTA extra batteries into a DPU.

BLADE EB - an Interesting Surprise

There is this little surprise of an extra battery, the BLADE extra battery, which looks like a DELTA 2 that has no display, no USB ports and is weather resistant. There isn't much information about this other than a product page and a tutorial video (Youtube). It has an XT-150 port and a special PV input port (this might be the same port that is used on PowerStream - only folks on the other side of the puddle can get this) with adapters that allow you to power a BLADE base as well as charge it with the BLADE power supply. According to the video can also act as an extra battery to a DELTA 2 or use a DELTA 2 as an extra battery.

Can a solar generator become an extra battery to another solar generator?

One question that is often asked is whether you can plug two DELTA Pros together or a DELTA 2 to a DELTA Max with extra battery cables to get one to work as an extra battery to the other. The answer is a definitive

Only extra batteries, Smart Generators, or WAVEs can be connected to the extra battery ports. You cannot plug a solar generator into the extra battery port of another solar generator.

Note, there are ways to get two DELTA Pros to work together, but that is using a Double Voltage Hub with a Victron AutoTransformer or a Smart Home Panel in 120v mode... a discussion for a future article.

Bottom Line

Most extra batteries only work with the same-named solar generator or smart device, but there are just a few exceptions. Then there is this little surprise of an extra battery, the BLADE Smart Extra Battery, which looks like a DELTA 2 that has no display, no USB ports and is weather resistant.
